PACKING
Olympus Seal and Supply offers a range of pump packing products used in valve, rotary, & reciprocating pump applications, and we also stock an extensive range of sizes. Contact us for help with your packing needs today!
GFO
GFO Packing can be used in rotary, reciprocating and static sealing applications handling most chemical media. Exceptions are molten alkali metals and strong oxidizing media such as oleum, aqua-regia and fuming nitric acid. It is particularly good in sealing water, steam, slurries, oils, acids and alkalis. Typical sealing applications include petrochemical, chemical, brewing, paper and pulp industries. We are your premier packing supplier!
Approval FDA
Maximum Temperature 260°C / 500°F
Media Hazardous
Minimum Temperature -100°C / -148°F
Pressure 200 Bars / 2900.76 PSI
Style American Braiding 8000T / Sepco ML4002
GRAPHITE
Diagonally braided from pure, expanded flexible graphite, reinforced at the corners and throughout with high-quality carbon fibers. The carbon fiber reinforcement in the corners and body of the packing make it three times more resistant to extrusion and also increase the pressure handling capabilities compared to non-reinforced flexible graphite packing. Contact us -your packing supplier!
Maximum Temperature 450°C / 842°F
Minimum Temperature -240°C / -400°F
pH 0-14
Pressure 200 Bars / 2900.76 PSI
Style Teadit 2202
THERMICULITE
Thermiculite® 894 is a flexible gasket compression packing, made by over-knitting strips of Thermiculite® foil with a fine Inconel 600 wire & then braiding a those Thermiculite /Inconel strips to produce a square section of sealing material available in continuous roll form.
Brand Thermiculite®
Media Hazardous
Maximum Temperature 1000°C / 1832°F
Minimum Temperature 0°C / 32°F
Pressure 0 Bars / 0.00 PSI
Style Flexitallic 894
PTFE / FDA
Our FDA Grade PTFE packing complies with the FDA and USDA requirements under Title 21 Food and Drugs, 178.2570, Lubricants with Incidental Food Conact, 177.1550, Perfluorocarbon Resins. It only contains materials permitted for food contact use by the U.S. Department of Agriculture and the Food and Drug Administration.
Approval FDA, Oxygen Service
pH 0-14
Maximum Temperature 260°C / 500°F
Minimum Temperature -100°C / -148°F
Pressure 200 Bars / 2900.76 PSI
Style Sepco 2236FDA
GENERAL SERVICE
General Service packing can be used in rotary and reciprocating applications specifically for the marine industry. It has a relatively high level of chemical & wear resistance with low friction properties, resistant to pressure and does not swell or rot in water. It provides a long service life. This is an economic packing for general & marine applications. The strong yet conformable nature provides high pressure sealing to be achieved over a long time. Typical sealing applications include cold and warm fresh and sea water, potable water, solutions with solid particles, oils & solvents.
Approval FDA
Maximum Temperature 120°C / 248°F
Media Hazardous
Minimum Temperature -40°C / -40°F
Pressure 70 Bars / 1015.27 PSI
PACKING SETS
Die formed or pre-formed packing sets provide an effective solution by allowing the distribution of mechanical pressure evenly along the entire sleeve. This design also plays a crucial role in helping to eliminate the fine leak paths that can exist between the individual fibers of packing materials. Additionally, these packing sets can be manufactured from virtually any type of packing product, offering versatility in various applications.
